CKN6-10/1N/B/001-DE Wył.nadpr. z mod. różnic., 1+N-bieg.

Information	Value
Supplier	EATON Electric Sp. z o.o. (MOELLER)
Symbol	241093
GTIN(EAN)	4015082410933
Price unit	piece
Product withdrawn	This product is not produced any more. It might still be available if some wholesaler has it in it's stock

The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.

Additional features:

Information	Value
ETIM class:	Earth leakage circuit breaker
Number of poles (total):	2
Number of protected poles:	1
Rated voltage:	230 V
Rated insulation voltage Ui:	250 V
Rated impulse withstand voltage Uimp:	4 kV
Rated current:	10 A
Rated fault current:	0.01 A
Leakage current type:	AC
Current limiting class:	3
Rated short-circuit breaking capacity according to EN 61009:	6 kA
Rated short-circuit breaking capacity according to IEC 60947-2:	0 kA
Rated short-circuit breaking capacity Icn according to EN 61009-1:	6 kA
Surge current capacity:	0.25 kA
Voltage type:	AC
Frequency:	50 Hz
Release characteristic:	B
Concurrently switching neutral conductor:	yes
With interlocking device:	no
Over voltage category:	3
Pollution degree:	2
Ambient temperature during operating:	-25 - 40 °C
Width in number of modular spacings:	2
Built-in depth:	69.5 mm
Anti-nuisance tripping version:	no
Degree of protection (IP):	IP20
Connectable conductor cross section solid-core:	1 - 25 mm²
Connectable conductor cross section multi-wired:	1 - 25 mm²
