Z-LAR16-O Przekaźnik priorytet., 1 rozw., 10-16 A
| Information | Value |
|---|---|
| Supplier | EATON Electric Sp. z o.o. (MOELLER) |
| Symbol | 248257 |
| GTIN(EAN) | 4015082482572 |
| Price unit | piece |
| Catalog price | 620,29 zł (504,30 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Lastafschakelrelais (stroom), nominaal bedrijfsstroom bereik 10-16 A, geïntegreerd hulpcontact: 1 nc, nominale spanning 250 V, nominale isolatiespanning 440 V, nom. stootspanningsvastheid 4 kV, standaardafmeting voorkant 45 mm, montagebreedte 1 MU (17,5 mm), DIN-rail montage, klemdoorsnede hoofdcircuit 2x10 mm², klemdoorsnede hulpcircuit 2x2,5 mm²
Additional features:
| Information | Value |
|---|---|
| Net weight: | 106 g |
| Country of origin | Czechy |
| ETIM class: | Load shedding relay for distribution board |
| Rated voltage: | 250 V |
| Max. time-delayed switch-off: | 0 ms |
| Max. continuous current: | 16 A |
| Number of contacts as normally open contact: | 0 |
| Number of contacts as normally closed contact: | 1 |
| Number of contacts as change-over contact: | 0 |
| Rated current (control contacts): | 1 A |
| Max. switching voltage (control contacts): | 250 V |
| Max. switching power (control contacts): | 4,66 VA |
| Electrical lifespan (control contacts): | 100 000 c |
| Mechanical lifetime (control contacts): | 0 c |
| Max. electrical switching cycles: | 3 600 c/h |
| Voltage type: | AC |
| Mounting method: | DIN rail |
| Width in number of modular spacings: | 1 |
| Built-in depth: | 60 mm |
| Degree of protection (IP): | IP20 |
