SPI-100/NPE ; Ogranicznik przepięć klasy B

Information	Value
Supplier	EATON Electric Sp. z o.o. (MOELLER)
Symbol	263139
GTIN(EAN)	4015082631390
Price unit	piece
Product withdrawn	This product is not produced any more. It might still be available if some wholesaler has it in it's stock

The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.

Description:

Odgromnik: zastosowanie zgodnie z IEC60364-5-53 Clause 534 Do zabezpieczania odbiorników w instalacjach

Additional features:

Information	Value
ETIM class:	Lightning current arrester for power supply systems
System configuration DC:	no
System configuration IT:	no
System configuration TN:	no
System configuration TN-C:	no
System configuration TN-C-S:	no
System configuration TN-S:	no
System configuration TT:	no
System configuration other:	no
Lightning impulse current (10/350 µs):	100 kA
Nominal discharge surge current (8/20):	100 kA
Max. continuous voltage AC:	260 V
Max. continuous voltage DC:	0 V
Nominal voltage AC:	0 V
Nominal voltage DC:	0 V
Voltage protection level:	1.5 kV
Voltage protection level L-N:	0 kV
Voltage protection level N-PE:	0 kV
Voltage protection level (DC+ - DC-):	0 kV
Voltage protection level (DC+/DC- - PE):	0 kV
Follow current extinguishing capability:	0 kA
Specific energy (W/R):	0 kJ/Ω
Mounting method:	DIN rail (top hat rail) 35 mm
Construction size:	2 modular spacing
Max. conductor cross section solid (solid, stranded):	50 mm²
Max. conductor cross section flexible (fine-strand):	35 mm²
With remote signalling contact:	no
Exhausting:	no
Signalling at the device:	Optical
Category type 1:	yes
Integrated backup fuse:	no
Suitable for outdoor use:	no
