Plafoniera LED z czujnikiem ruchu DRM-04
| Information | Value |
|---|---|
| Supplier | F&F Filipowski Spółka Komandytowa |
| Series | DR |
| Symbol | DRM-04 |
| GTIN(EAN) | 5908312594659 |
| Price unit | piece |
| Catalog price | 528,90 zł (430,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
-
Promocja F&F - zegar astronomiczny
Za zakup asortymentu F&F na kwotę 2500 zł., zegar astronomiczny w cenie 3,69 zł.
-
Hager, Kontakt Simon, F&F - Razem na wiosnę - miksuj dowolnie
Kup produkty Hager, Kontakt Simon i F&F za kwotę 2000 zł netto i odbierz bezrękawnik
Description:
Napięcie zasilania 230 V AC Próg zadziałania - regulowany 2÷2000 Lx Opóźnienie zadziałania mniej niż 1 s Częstotliwość promieniowania mikrofalowego 5,8 GHz Maksymalna moc promieniowania 10 mW Czas załączenia odbiornika - regulowany 5 sek ÷ 15 min. Pole detekcji poziomej 360° Maks. regulowany promień detekcji (h: 2.5 m, Temp. ˂ 24 °C) 2÷10 m Wysokość montażu czujnika 2,0÷6,0 m Źródło światła 96 x LED Barwa światła zimna, 6000 K Strumień świetlny 1030 Lm Moc elektryczna LED 15 W Pobór mocy czujnika ruchu 0,9 W Rodzaj detekcji promieniowanie mikrofalowe Przyłącze zaciski śrubowe 1,5 mm² Moment dokręcający 0,3 Nm Temperatura pracy -25 ÷ 50 °C Wymiary Ø295 mm; h:100 mm Montaż 4 wkręty do podłoża
Additional features:
| Information | Value |
|---|---|
| Gross weight: | 122 g |
| ETIM class: | Ceiling-/wall luminaire |
| Suitable for suspended mounting: | no |
| Suitable for ceiling mounting: | yes |
| Suitable for built-in mounting: | no |
| Suitable for surface mounting: | yes |
| Suitable for light line configuration: | no |
| Lamp type: | LED not exchangeable |
| With light source: | yes |
| Suitable for number of light sources: | 96 |
| Housing material: | Plastic |
| Housing colour: | White |
| Material cover: | Plastic matt/satinized |
| Voltage type: | AC |
| Nominal voltage: | 230 - 230 V |
| With control gear: | no |
| Degree of protection (IP): | IP40 |
| Suitable for emergency lighting: | no |
| With movement sensor: | yes |
| Luminaire efficacy: | 15 lm/W |
| Rated luminous flux according to IEC 62722-2-1: | 1 030 lm |
| Height/depth: | 100 mm |
| Outer diameter: | 295 mm |
| Connection type: | Screwed terminal |
| Suitable for wall mounting: | yes |
| Suitable for workplace according to EN 12464-1: | no |
| Exchangeable control gear: | no |
| Dimming 0-10 V: | no |
| Dimming 1-10 V: | no |
| Dimming DALI-2: | no |
| Dimming DALI: | no |
| Dimming DMX: | no |
| Dimming DSI: | no |
| Dimming potentiometer (integrated): | no |
| Dimming LineSwitch: | no |
| Dimming manufacturer's proprietary system: | no |
| Dimming mains voltage modulation: | no |
| Dimming phase cut-off: | no |
| Dimming phase cut-on: | no |
| Dimming programmable: | no |
| Dimming RF: | no |
| Dimming Sine Wave Reduction: | no |
| Dimming Touch and Dim: | no |
| Dimming Zigbee: | no |
| Dimming with push-button: | no |
| No dim function: | no |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24: | no |
| Emergency power supply integrated: | no |
| With light sensor: | no |
| Covering of the luminaire with thermally insulating material possible: | no |
| With air slots: | no |
| Constant light output (CLO): | no |
| Operation by Bluetooth: | no |
| Compatible with Casambi: | no |
| Compatible with Apple HomeKit: | no |
| Compatible with Google Assistant: | no |
| Compatible with Amazon Alexa: | no |
| IFTTT support available: | no |
