Przekaźnik zdalnego sterowania GSM (SMS); 4xWY, 4xWE; załącz/wyłącz/powiadom; 230V AC; 4x1NO; montaż na szynie DIN
Information | Value |
---|---|
Supplier | F&F Filipowski Spółka Komandytowa |
Series | GSM |
Symbol | SIMplyMAX-P04 |
GTIN(EAN) | 5908312599777 |
Price unit | piece |
Catalog price | 1 020,90 zł (830,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Description:
Napięcie zasilania 230 V AC Element wykonawczy 4 x przekaźnik Maksymalny prąd obciążenia 8 A Konfiguracja styków 4×NO Wejścia ilość 4 Wejścia - tolerancja napięciowa 160÷260 V AC Porty SIM, mini USB Typ złącza anteny SMA Antena GSM wymiary 20 mm x 100 mm Długość przewodu anteny 2,5 m Przyłącze zaciski śrubowe 4,0 mm² Moment dokręcający 0,5 Nm Pobór mocy czuwanie/praca 1,3 W / 3 W Temperatura pracy -10÷50°C Wymiary 5 modułów (87,5 mm) Montaż na szynie 35 mm Stopień ochrony IP20
Additional features:
Information | Value |
---|---|
ETIM class: | Switching relay |
Type of electric connection: | Screw connection |
With detachable clamps: | no |
Rated control supply voltage AC 50 Hz: | 160 - 260 V |
Voltage type for actuating: | AC |
Number of contacts as change-over contact: | 4 |
Type of switch contact: | Double contact |
Nominal current: | 8 A |
Degree of protection (IP): | IP20 |
Width: | 70 mm |
Height: | 90 mm |
Depth: | 65 mm |
