RCBO Wyłącznik różnicowoprądowy z członem nadprąd. 1P+N 6kA B 16A/30mA Typ A QC
Information | Value |
---|---|
Supplier | HAGER POLO Sp. z o. o. (Berker) |
Symbol | ADS916D |
GTIN(EAN) | 3250611068143 |
Price unit | piece |
Catalog price | 651,90 zł (530,00 zł + 23% VAT) |
Promotions related to this product
-
Promocja Hager
Za zakup asortymentu firmy Hager odbierz jedną z nagród: organizer lub bluzę 4F.
-
Wiosenna Promocja z Hager-em
Kup Produkty Firmy Hager i odbierz nagrodę.
Promotion active until 05/31/2024
-
Szybki print !
Przy zakupach marki HAGER za kwotę 5000 zł brutto w ElektRa Hurtownia Elektrotechniczna otrzymasz drukarkę XIAOMI Mi Portable Photo Printer !!
-
HAGER: Rozdajemy narzędzia Wiha!
Kup produkty marki HAGER za min 1000 zł netto i otrzymaj narzędzie Wiha.
Promotion active until 05/31/2024
Additional features:
Information | Value |
---|---|
Gross weight: | 224 g |
ETIM class: | Earth leakage circuit breaker |
Rated current: | 16 A |
With interlocking device: | yes |
Rated insulation voltage Ui: | 500 V |
Voltage type: | AC |
Frequency: | 50 Hz |
Rated impulse withstand voltage Uimp: | 4 kV |
Rated fault current: | 0.03 A |
Ambient temperature during operating: | -25 - 40 °C |
Leakage current type: | A |
Rated short-circuit breaking capacity according to IEC 60947-2: | 6 kA |
Rated short-circuit breaking capacity Icn according to EN 61009-1: | 6 kA |
Over voltage category: | 3 |
Disconnection characteristic: | Undelayed |
Number of protected poles: | 1 |
Release characteristic: | B |
Number of poles (total): | 2 |
Built-in depth: | 68 mm |
Rated voltage: | 240 V |
Anti-nuisance tripping version: | no |
Surge current capacity: | 0.25 kA |
Concurrently switching neutral conductor: | yes |
Pollution degree: | 2 |
Width in number of modular spacings: | 2 |
Current limiting class: | 3 |
Flush-mounted installation: | yes |
Degree of protection (IP): | IP2X |
