SPD T1 N-PE Iimp=100kA In=100kA Up=≤ 1,5 kV styk
Information | Value |
---|---|
Supplier | HAGER POLO Sp. z o. o. (Berker) |
Symbol | SPA180N |
GTIN(EAN) | 3250615515063 |
Price unit | piece |
Catalog price | 1 260,75 zł (1 025,00 zł + 23% VAT) |
Promotions related to this product
-
Promocja Hager
Za zakup asortymentu firmy Hager odbierz jedną z nagród: organizer lub bluzę 4F.
-
Wiosenna Promocja z Hager-em
Kup Produkty Firmy Hager i odbierz nagrodę.
Promotion active until 05/31/2024
-
Szybki print !
Przy zakupach marki HAGER za kwotę 5000 zł brutto w ElektRa Hurtownia Elektrotechniczna otrzymasz drukarkę XIAOMI Mi Portable Photo Printer !!
-
HAGER: Rozdajemy narzędzia Wiha!
Kup produkty marki HAGER za min 1000 zł netto i otrzymaj narzędzie Wiha.
Promotion active until 05/31/2024
Additional features:
Information | Value |
---|---|
Gross weight: | 370 g |
ETIM class: | Lightning current arrester for power supply systems |
Max. conductor cross section solid (solid, stranded): | 35 mm² |
System configuration TN-S: | yes |
Follow current extinguishing capability: | 50 kA |
System configuration TT: | yes |
Max. continuous voltage AC: | 350 V |
Mounting method: | DIN rail (top hat rail) 15 mm |
Voltage protection level N-PE: | 1.5 kV |
Number of conductors (without earthing): | 1 |
Integrated backup fuse: | yes |
Voltage protection level: | 1.5 kV |
Nominal discharge surge current (8/20): | 100 kA |
Construction size: | 2 modular spacing |
Lightning impulse current (10/350 µs): | 100 kA |
Signalling at the device: | Optical |
Max. conductor cross section flexible (fine-strand): | 35 mm² |
System configuration TN: | yes |
Exhausting: | no |
System configuration other: | no |
Nominal voltage AC: | 240 V |
System configuration TN-C: | yes |
System configuration TN-C-S: | yes |
Suitable for outdoor use: | no |
Degree of protection (IP): | IP20 |
With remote signalling contact: | yes |
Category type 1: | yes |
Order
Additional information:
Information | Value |
---|---|
Updated: | 2024-04-04 12:46:17 |
Files to download: | |
External links: |
