Ex9CL-H 2P 63A 30mA Wył. różn., Icn=10kA, 2-bieg., In=63A, IΔn=30mA, typ AC
| Information | Value |
|---|---|
| Supplier | NOARK Electric Sp. z o.o. |
| Symbol | 100649 |
| GTIN(EAN) | 8592765006509 |
| Price unit | piece |
| Product withdrawn | This product is not produced any more. It might still be available if some wholesaler has it in it's stock |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Additional features:
| Information | Value |
|---|---|
| Net weight: | 240 g |
| ETIM class: | Residual current circuit breaker (RCCB) |
| Mounting method: | DIN rail |
| Built-in depth: | 78 mm |
| Rated current: | 63 A |
| Rated voltage: | 230 V |
| Number of poles: | 2 |
| Rated fault current: | 0.03 mA |
| Leakage current type: | AC |
| Selective protection: | yes |
| Short-circuit breaking capacity (Icw): | 10 kA |
| Surge current capacity: | 0.25 kA |
| Width in number of modular spacings: | 2 |
| Short-time delayed tripping: | yes |
| Frequency: | 50/60 Hz |
| Degree of protection (IP): | IP20 |
| Additional equipment possible: | yes |
buy at the outlet / on sale
Wholesaler / branch / Address
Distance
Available
Price
Actions
Bychowo-Hel Hurtownia Elektryczna o/Kwidzyn
Kwidzyn, Toruńska 34
Kwidzyn, Toruńska 34
Distance:
4 sztuki
174,66 zł/szt.
Additional information:
| Information | Value |
|---|---|
| Updated: | 2022-12-03 12:18:28 |
| Files to download: |
