BBP 3L 10 M54 EU Szyna łączeniowa typ trzpieniowy, 3 bieg., 10mm² 54 mod. (1m) do serii Ex9B krok 18mm
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 113241 |
GTIN(EAN) | 8592765132413 |
Price unit | piece |
Catalog price | 187,50 zł (152,44 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Promotions related to this product
Additional features:
Information | Value |
---|---|
Net weight: | 480 g |
ETIM class: | Phase busbar |
Number of phases: | 3 |
Number of poles: | 3 |
Suitable for number of devices: | 54 |
Module width: | 18 mm |
Cross section: | 10 mm² |
Length: | 1000 mm |
Can be cut to size: | yes |
Width in number of modular spacings: | 54 |
Rated permanent current Iu: | 63 A |
Type of electric connection: | Pin |
Insulated: | yes |
Rated surge voltage: | 4 kV |
Max. rated operation voltage Ue: | 400 V |
Suitable for devices with N-conductor: | no |
Suitable for devices with auxiliary switch: | no |
Colour: | White |
