Stycznik modułowy Acti9 iCT50r-63-40-230 63A 4NO 50/60Hz 220/240 VAC
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | A9C21864 |
GTIN(EAN) | 3606480096891 |
Price unit | piece |
Catalog price | 1 025,82 zł (834,00 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Stycznik modułowy serii iCT, o numerze A9C21864, iCT50r-63-40-230, napięcie sterowania 220/240 VAC 50Hz, 4 styki zwierne, prąd znamionowy AC7A: 63 A, do sterowania obwodami elektrycznymi. Wyposażony w dźwignię ręcznego sterowania Załączony-Auto-Wyłączony pozwalający na lokalne sterowanie. enterOptyczny wskaźnik st anu styków wyjściowych, możliwość rozbudowy o styki pomocnicze
Additional features:
Information | Value |
---|---|
punkty elektroklub: | 19 |
Gross weight: | 362 g |
ETIM class: | Installation contactor for distribution board |
Built-in depth: | 43.5 mm |
Additional equipment possible: | yes |
Rated operation current: | 63 A |
Voltage type (excitation voltage): | AC |
Voltage type (operating voltage): | AC |
Degree of protection (IP): | IP20 |
Rated operating voltage: | 400 - 400 V |
Rated excitation voltage: | 220 - 240 V |
Max. load fluorescent lamp: | 11550 VA |
Max. load fluorescent lamp (Duo circuit): | 17700 VA |
Width in number of modular spacings: | 3 |
Max. load fluorescent lamp (parallel compensated): | 10500 VA |
Max. incandescent lamp load: | 22500 W |
Number of contacts as normally open contact: | 4 |
Number of contacts as normally closed contact: | 0 |
Slider for hand switch: | yes |
With day/night function: | no |
Hum-free: | no |
Utility category: | 7 |
