Wyłącznik, ComPacT NSXm, TM100D, 3P, 25kA, EverLink
Information | Value |
---|---|
Supplier | Schneider Electric Polska Sp. z o.o. |
Symbol | C11B3TM100L |
GTIN(EAN) | 3606481990037 |
Price unit | piece |
Catalog price | 1 249,05 zł (1 015,49 zł + 23% VAT) |
Promotions related to this product
-
Elektroklub - Nagrody dla każdego! od Schneider Electric
Nagrody dla każdego! Nawet 2x więcej punktów kupując Schneider Electric
Promotion active until 04/30/2024
-
Elektroklub - Start Promocji - Łowcy przygód 2024 – wiatr i woda – edycja wiosenna
Jesteś elektrykiem, lubisz aktywnie wypoczywać, poznawać nowych ludzi i ciekawe miejsca? To
mamy ogłoszenie specjalnie dla Ciebie.Promotion active until 04/30/2024
Additional features:
Information | Value |
---|---|
punkty elektroklub: | 63 |
Gross weight: | 1,206 kg |
ETIM class: | Power circuit-breaker for trafo/generator/installation protection |
Type of electrical connection of main circuit: | Screw connection |
Number of auxiliary contacts as change-over contact: | 0 |
Number of auxiliary contacts as normally open contact: | 0 |
Number of auxiliary contacts as normally closed contact: | 0 |
Adjustment range undelayed short-circuit release: | 1250 - 1250 A |
Integrated earth fault protection: | no |
Device construction: | Built-in device fixed built-in technique |
Suitable for DIN rail (top hat rail) mounting: | yes |
Degree of protection (IP): | IP40 |
Number of poles: | 3 |
Rated voltage: | 690 - 690 V |
DIN rail (top hat rail) mounting optional: | no |
Complete device with protection unit: | yes |
With switched-off indicator: | yes |
Motor drive integrated: | no |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz: | 25 kA |
Overload release current setting: | 70 - 100 A |
Type of control element: | Toggle |
Rated permanent current Iu: | 100 A |
Motor drive optional: | no |
Position of connection for main current circuit: | Front side |
Order
Additional information:
Information | Value |
---|---|
Updated: | 2024-04-02 15:10:56 |
Files to download: | |
External links: |
