| ETIM class: |
Downlight/spot/floodlight
|
| Suitable for surface mounting: |
yes |
| Suitable for low voltage cable system: |
no |
| Adjustability: |
Rotating and swivelling |
| With movement sensor: |
no |
| With light sensor: |
no |
| Lamp type: |
LED not exchangeable |
| With light source: |
yes |
| Lamp holder: |
None |
| Housing material: |
Aluminium |
| Surface protection: |
Powder coating |
| Suitable for built-in mounting: |
no |
| Housing colour: |
Aluminium |
| Material cover: |
Glass structured |
| Surface brushed: |
no |
| Voltage type: |
AC |
| Nominal voltage: |
220 - 240 V |
| Type of control gear: |
LED operating device current-controlled |
| With control gear: |
yes |
| Dimming depending on control gear: |
no |
| Dimming 0-10 V: |
no |
| Suitable for wall mounting: |
yes |
| Dimming 1-10 V: |
no |
| Dimming DALI: |
no |
| Dimming DMX: |
no |
| Dimming DSI: |
no |
| Dimming potentiometer (integrated): |
no |
| Dimming GPRS: |
no |
| Dimming LineSwitch: |
no |
| Dimming manufacturer's proprietary system: |
no |
| Dimming mains voltage modulation: |
no |
| Dimming phase cut-off: |
no |
| Suitable for suspended mounting: |
no |
| Dimming phase cut-on: |
no |
| Dimming programmable: |
no |
| Dimming RF: |
no |
| Dimming Sine Wave Reduction: |
no |
| Dimming Touch and Dim: |
no |
| Dimming Zigbee: |
no |
| Dimming with push-button: |
no |
| No dim function: |
yes |
| Reflector: |
White |
| Light distributor: |
Reflector |
| Suitable for ceiling mounting: |
no |
| Light sharing: |
Symmetric |
| Beam angle: |
Extreme wide beam >80° |
| Light outlet: |
Direct |
| Total harmonic distortion: |
25 |
| Suitable for traverse mounting: |
no |
| Degree of protection (IP): |
IP65 |
| Impact strength: |
IK06 |
| Protection class: |
I |
| Rated ambient temperature according to IEC 62722-2-1: |
-40 - 50 °C |
| Suitable for pedestal/floor mounting: |
yes |
| Max. system power: |
20 W |
| Colour of light: |
White |
| Colour temperature: |
4 000 - 4 000 K |
| Colour rendering index CRI: |
80-89 |
| Luminous flux: |
1 530 - 1 870 lm |
| Rated luminous flux according to IEC 62722-2-1: |
1 700 lm |
| Lamp efficacy: |
85 lm/W |
| Luminous intensity: |
626,2 cd |
| Power factor: |
0,9 |
| Suitable for light-track mounting: |
no |
| Width: |
28 mm |
| Height/depth: |
110 mm |
| Length: |
140 mm |
| Built-in width: |
140 mm |
| Built-in height/depth: |
132,5 mm |
| Built-in length: |
140 mm |
| Built-in diameter: |
132,5 mm |
| Type of wiring: |
Ending |
| Number of poles: |
3 |
| Suitable for clamp-mounting: |
no |
| Conductor cross section: |
1 mm² |
| Connectable conductor cross section: |
1 - 1 mm² |
| Connection type: |
Other |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24: |
no |
| Luminaire efficacy: |
85 lm/W |
| Suitable for workplace according to EN 12464-1: |
no |
| Covering of the luminaire with thermally insulating material possible: |
no |
| Filament test according to IEC 60695-2-11: |
650 °C - 30 s |
| Photobiological safety according to EN 62471: |
RG1 |
| Colour consistency (McAdam ellipse): |
SDCM6 |
