BPZ-KB-11/160 Modułowy blok listew rozdzielczych,4bieg
Information | Value |
---|---|
Supplier | EATON Electric Sp. z o.o. (MOELLER) |
Symbol | 102716 |
GTIN(EAN) | 4015081025763 |
Price unit | piece |
Catalog price | 987,57 zł (802,90 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
4-pole terminal block, BPZ-KB, rated operational current 160 A, mounting on DIN-rail and mounting plate, max. operational voltage 1000 V AC , 1500 VDC. Equipment supplied: 1 4 pole terminal block
Additional features:
Information | Value |
---|---|
Net weight: | 706 g |
ETIM class: | Distributor assembly terminal blocks |
Width: | 160.4 mm |
Height: | 86 mm |
Depth: | 50.2 mm |
Number of poles: | 4 |
Number of clamp positions per pole: | 12 |
Conductor cross section flexible (fine-strand) with cable end sleeve: | 2.5 - 50 mm² |
Conductor cross section solid (solid, stranded): | 2.5 - 50 mm² |
Max. rated current: | 160 A |
With N-rail: | no |
With PE-rail: | no |
