PXS24E-e4/F Wyłącznik elektroniczny selektywny bez modułu komunikacji, bez zacisków wtykowych, In=4A, Un=24 VDC, seria PXS24
| Information | Value |
|---|---|
| Supplier | EATON Electric Sp. z o.o. (MOELLER) |
| Symbol | PXS24E04A002 |
| GTIN(EAN) | 9010238011304 |
| Price unit | piece |
| Catalog price | 765,18 zł (622,10 zł + 23% VAT) |
The given prices do not constitute an offer within the meaning of the Civil Code. The purchase prices of a given item may differ from those displayed.
Description:
Zuverlässiger modularer elektronischer Überlastschutz für 24V DC-Systeme, einfache Verschienung, fixer oder variabler Amperage, optional mit Steuerungsein- und Fehlermeldungsausgang, Steckklemmen (+ 24 V und 0 V) für bis zu 3 Lasten, robustes Design, lokal und (optional) ferngesteuert
Additional features:
| Information | Value |
|---|---|
| Net weight: | 118 g |
| Country of origin | Czechy |
| ETIM class: | Current monitoring relay |
| Type of electric connection: | Plug-in connection |
| With detachable clamps: | no |
| Single-phase under current possible: | no |
| Three-phase under current possible: | no |
| Single-phase overcurrent possible: | no |
| Three-phase overcurrent possible: | no |
| Single-phase hysteresis possible: | no |
| Three-phase hysteresis possible: | no |
| Contains function DC-voltage under current: | no |
| Contains function DC-voltage overcurrent: | yes |
| Function DC-current hysteresis: | no |
| Current measuring range: | 0 - 5,2 A |
| Min. adjustable delay-on energization time: | 0 s |
| Max. permitted delay-on energization time: | 0 s |
| Min. adjustable off-delay time: | 0 s |
| Max. permitted off-delay time: | 0 s |
| Number of contacts as normally closed contact: | 0 |
| Number of contacts as normally open contact: | 1 |
| Number of contacts as change-over contact: | 0 |
| External current transformer: | no |
| Width: | 18 mm |
| Height: | 93 mm |
| Depth: | 127 mm |
| External power supply required: | no |
| Voltage type (supply voltage): | DC |
| Supply voltage DC: | 15 - 30 V |
| Type of current: | DC |
| Voltage type (operating voltage): | DC |
| Operating voltage DC: | 15 - 30 V |
| Rated switch current: | 4 A |
