MCCB Wyłącznik mocy x160 3P 25kA 63A TM
Information | Value |
---|---|
Supplier | HAGER POLO Sp. z o. o. (Berker) |
Symbol | HHA063H |
GTIN(EAN) | 3250613130473 |
Price unit | piece |
Catalog price | 2 013,51 zł (1 637,00 zł + 23% VAT) |
Promotions related to this product
-
Promocja Hager
Za zakup asortymentu firmy Hager odbierz jedną z nagród: organizer lub bluzę 4F.
-
Wiosenna Promocja z Hager-em
Kup Produkty Firmy Hager i odbierz nagrodę.
Promotion active until 05/31/2024
-
Szybki print !
Przy zakupach marki HAGER za kwotę 5000 zł brutto w ElektRa Hurtownia Elektrotechniczna otrzymasz drukarkę XIAOMI Mi Portable Photo Printer !!
-
HAGER: Rozdajemy narzędzia Wiha!
Kup produkty marki HAGER za min 1000 zł netto i otrzymaj narzędzie Wiha.
Promotion active until 05/31/2024
Additional features:
Information | Value |
---|---|
Gross weight: | 1,056 kg |
ETIM class: | Power circuit-breaker for trafo/generator/installation protection |
Rated permanent current Iu: | 63 A |
Overload release current setting: | 40 - 63 A |
Number of auxiliary contacts as change-over contact: | 0 |
Integrated earth fault protection: | no |
With switched-off indicator: | yes |
Motor drive optional: | no |
Motor drive integrated: | no |
Suitable for DIN rail (top hat rail) mounting: | yes |
Position of connection for main current circuit: | Front side |
Number of poles: | 3 |
Adjustment range undelayed short-circuit release: | 1000 - 1000 A |
Type of electrical connection of main circuit: | Screw connection |
Type of control element: | Toggle |
DIN rail (top hat rail) mounting optional: | no |
Complete device with protection unit: | yes |
Rated voltage: | 220 - 415 V |
Degree of protection (IP): | IP40 |
Device construction: | Built-in device fixed built-in technique |
Number of auxiliary contacts as normally closed contact: | 0 |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz: | 25 kA |
Number of auxiliary contacts as normally open contact: | 0 |
With integrated under voltage release: | no |
