Ex9SN25B 18A Wyłącznik silnikowy Ex9SN, przyciskowy, 13-18A
Information | Value |
---|---|
Supplier | NOARK Electric Sp. z o.o. |
Symbol | 108951 |
GTIN(EAN) | 8592765089519 |
Price unit | piece |
Catalog price | 167,29 zł (136,01 zł + 23% VAT) |
Promotions related to this product
-
Are you reals ? !
Dokonaj zakupów produktów NOARK na kwotę powyżej 1500 zł brutto, a w prezencie otrzymasz Uchwyt Selfie marki VÖGEL BSF305K !
-
LETNIE ORZEŹWIENIE
Przy zakupach produktów NOARK w ElektRa Hurtownia Elektrotechniczna na kwotę 5000 zł brutto otrzymasz prezent Saturator Brita SodaOne
Additional features:
Information | Value |
---|---|
Net weight: | 290 g |
ETIM class: | Motor protection circuit-breaker |
Overload release current setting: | 13 - 18 A |
Phase failure sensitive: | yes |
Switch off technique: | Thermomagnetic |
Rated operating voltage: | 230 - 690 V |
Rated permanent current Iu: | 18 A |
Rated operation power at AC-3, 230 V: | 4 kW |
Rated operation power at AC-3, 400 V: | 7.5 kW |
Type of electrical connection of main circuit: | Frame clamp |
Type of control element: | Push button |
Device construction: | Complete device in housing |
With integrated auxiliary switch: | no |
With integrated under voltage release: | no |
Number of poles: | 3 |
Rated short-circuit breaking capacity lcu at 400 V, AC: | 15 kA |
Degree of protection (IP): | IP20 |
Height: | 81 mm |
Width: | 44.5 mm |
Depth: | 91.3 mm |
Power loss: | 9 W |
